Graphing linear equations for kids: from an equation to a line
A linear equation such as y = 2x − 1 looks like a rule, and a graph looks like a picture, so it is easy for a child to treat them as two separate topics. They are the same thing. The equation is a recipe that turns any x into a y, and the graph is every result of that recipe drawn on one page. Once a child sees that every point on the line is an answer to the equation, graphing stops being a list of steps to memorise.
Try this tonight
4 things you can do at home
Make a three-row table before touching the graph paper
Pick x = 0, 1 and 2 (or any three easy values) and work out y for each. Writing the table down keeps the arithmetic separate from the plotting, so when a point looks wrong it is clear which of the two jobs went astray.
Plot each point as a pair: along first, then up or down
Say "along, then up" out loud for every point, such as (1, 1): one along, one up. Swapping the two coordinates is the most common plotting slip, and it is cheap to catch while the points are being marked.
Join the points with a ruler and extend past them
The line carries on in both directions, so draw it across the whole grid and add arrows at the ends. Three points should line up exactly. If one sits off the line, go back to the table and recheck that row.
Test one extra point
Read a point off the line that was not in the table, put its x into the equation and see whether the y matches. This takes thirty seconds and proves the graph is right rather than hoping it is.
What the line actually shows
Each point on the line is a pair (x, y) that makes the equation true, and each point off the line does not. For y = 2x − 1, the point (3, 5) is on the line because 2 × 3 − 1 = 5. The point (3, 4) is not, because 2 × 3 − 1 is 5, not 4.
The equation tells you two things about the line before you draw it. The number multiplying x is the slope (how steep the line is), and the number added or subtracted at the end is where the line crosses the vertical axis. In y = 2x − 1, the line goes up 2 for every 1 across and crosses the y-axis at −1.
A worked example: graph y = 2x − 1
Table of values. When x = 0, y = 2 × 0 − 1 = −1. When x = 1, y = 2 × 1 − 1 = 1. When x = 2, y = 2 × 2 − 1 = 3. The points are (0, −1), (1, 1) and (2, 3).
Plot them and join them with a ruler. Check against the equation: the line crosses the y-axis at −1, and each step of 1 along takes it up by 2, which matches the slope. For an extra test, x = 4 should give y = 7, and the line should pass through (4, 7).
The traps: a negative slope and a fraction slope
For y = −½x + 3, the line crosses the y-axis at 3. The slope is −½, so from (0, 3) go 2 along and 1 down to reach (2, 2), then 2 along and 1 down again to reach (4, 1). Check the last point: −½ × 4 + 3 = −2 + 3 = 1, which matches. Picking x-values that are even makes the table easy and avoids halves.
The other common slip is the sign of the starting point. In y = 2x − 1 the line crosses at −1, below the axis, not at +1. A child who plots (0, 1) will draw a line that is parallel to the right one but shifted up two squares, and every later point will look consistent with it, which makes the mistake hard to spot without the extra-point test.
Signs it’s time for outside help
When home help has done what it can
- Can plot points from a list but cannot make the list from an equation.
- Swaps the x and y coordinates when plotting, and does not notice the graph looks odd.
- Draws a line through only two points and never checks a third.
- Is unsure whether a point is on a line without graphing it again.
- Gets negative values in the table wrong, so the line slopes the wrong way.
- Cannot say what the number in front of x or the number at the end does to the line.
Questions parents ask
FAQ
What age do children usually learn to graph linear equations?
It usually appears around ages 13–15 (US Grades 8–9, England Key Stage 3 to 4, Australian Years 8–9), after children have worked with the coordinate plane and basic equations.
How many points do we really need to plot?
Two points fix a straight line, but plotting three is safer, because if the three do not line up, one of them is wrong. A fourth point from the graph, tested in the equation, is the best check.
What if the equation is written as 2x + 3y = 6 instead of y = ...?
It describes a line in the same way. A quick method is to set x = 0 to find where the line crosses the y-axis (y = 2) and set y = 0 to find where it crosses the x-axis (x = 3), then join (0, 2) and (3, 0). Rearranging to y = ... works too.
Why is the graph a straight line?
In a linear equation, y changes by the same amount for every equal step in x, so the points fall on a line. That is also why it is called "linear".
